Eric and others,
Here is a breakdown of what's currently decoded in GEMPAK7.4.1, one 5km MOS
grid and two versions of the 2.5km grid. Currently some of the 2.5km
GFSMOS has moved to a 2145x1597 grid, some is still being transmitted at
2145x1377.
When you say you only see PTYPE grids, which GFSMOS grid exactly do you
mean?
# 2.5km GFSMOS CONUS, 2145 x 1597 (current)
NGRID ^Y[A-JRSU-Y]U... KWBQ
PIPE dcgrib2 -v 1 -d data/gempak/logs/gfsmos.log
-e GEMTBL=/home/gempak/GEMPAK7/gempak/tables
data/gempak/model/mos/YYYYMMDDHH_gfsmos.gem
2017102500_gfsmos.gem
625 171025/0000F264 10 HGHT DRCT
626 171025/0000F264 10 HGHT SPED
627 171025/0000F264 2 HGHT TMPK
628 171025/0000F264 2 HGHT RELH
629 171025/0000F264 2 HGHT DWPK
630 171025/0000F264 2 HGHT TMXK12
631 171025/0000F264 0 NONE
PP120000PA
# 5km GFSMOS
HDS ^L.U... KWBQ
PIPE dcgrib2 -v 1 -d data/gempak/logs/gfsmos.log
-e GEMTBL=/home/gempak/GEMPAK7/gempak/tables
data/gempak/model/mos/YYYYMMDDHH_gfsmos5.gem
2017102500_gfsmos5.gem
1 171025/0000F015 0 NONE TSTM03
2 171025/0000F021 0 NONE TSTM03
3 171025/0000F039 0 NONE TSTM03
4 171025/0000F045 0 NONE TSTM03
5 171025/0000F063 0 NONE TSTM03
6 171025/0000F069 0 NONE TSTM03
7 171025/0000F075 0 NONE TSTM03
8 171025/0000F168 0 NONE TSTM12
9 171025/0000F174 0 NONE TSTM12
10 171025/0000F180 0 NONE TSTM12
11 171025/0000F186 0 NONE TSTM12
12 171025/0000F192 0 NONE TSTM12
# 2.5km GFSMOS CONUS, 2145 x 1377 (legacy?)
NGRID ^M[ABC]U... KWBQ
PIPE dcgrib2 -v 1 -d data/gempak/logs/gfsmos.log
-e GEMTBL=/home/gempak/GEMPAK7/gempak/tables
data/gempak/model/mos/YYYYMMDDHH_gfsmos-2145x1377.gem
NGRID ^Y[LMNZ]U... KWBQ
PIPE dcgrib2 -v 1 -d data/gempak/logs/gfsmos.log
-e GEMTBL=/home/gempak/GEMPAK7/gempak/tables
data/gempak/model/mos/YYYYMMDDHH_gfsmos-2145x1377.gem
2017102500_gfsmos-2145x1377.gem
1 171025/0000F006 0 NONE
PPXX0000PA
2 171025/0000F006 0 NONE
PTYPE0005000
3 171025/0000F006 0 NONE
PTYPE0003000
4 171025/0000F006 0 NONE
PTYPE0001000
5 171025/0000F006 0 NONE PTYPE
On Tue, Oct 24, 2017 at 11:58 AM, Eric Hoffman <ehoffman@xxxxxxxxxxxx>
wrote:
> Hi Robert, Gembud,
>
>
> We recently upgraded to GEMPAK 7.4.0 and made the suggested changes to our
> LDM entry as suggested in the release notes to address the gridded GFSMOS
> issue.
>
>
> However we are still experiencing the same problem as reported by Robert
> below. We also only get 189 grids and they are all PTYPE. Anyone have any
> ideas?
>
>
> Eric Hoffman
>
>
>
> [image: 1500566920211_business_card_signature.png]
> ------------------------------
> *From:* gembud-bounces@xxxxxxxxxxxxxxxx <gembud-bounces@xxxxxxxxxxxxxxxx>
> on behalf of Mullenax, Robert R. (WFF-820.0)[ORBITAL SCIENCES CORPORATION] <
> robert.r.mullenax@xxxxxxxx>
> *Sent:* Tuesday, August 15, 2017 3:03:41 PM
> *To:* gembud@xxxxxxxxxxxxxxxx
> *Subject:* [gembud] Issue with Gridded GFS MOS
>
> I have two systems, one running CentOS 7.2 and GEMPAK 7.3.1 and the other
> Solaris 11.3 running GEMPAK 7.2.0. I have the standard suggested entries
> for the Gridded GFS MOS but am only getting ptype in the decoded file.
>
> Here is my entry:
> # GFS MOS
> NGRID|HDS ^[LM].U... KWBQ
> PIPE /usr/local/ldm/decoders/dcgrib2 -v 1 -d
> /data/ldm/gempak/logs/gfsmos.log
> -e GEMTBL=/usr/gempak/GEMPAK/gempak/tables
> /data/ldm/gempak/model/mos/YYYYMMDDHH_gfsmos.gem
>
> The decoder log says 508 bulletins processed. The file has 189 grids, all
> ptype.
>
> Anyone else seeing this?
>
> Thanks,
> Robert Mullenax
>
>
>
> Please note new email address: robert.r.mullenax@xxxxxxxx
> Robert Mullenax
> Senior Principal Meteorologist, Orbital ATK/CSBF
> 1510 E. FM 3224
> Palestine, Texas 75802
> 903-723-8037 <(903)%20723-8037>
> robert.r.mullenax@xxxxxxxx
>
