Hi Tom, Thanks for the background information. > It should be possible to compute these vectors It would be great if we could get compatibility across the netcdf-java and proj4 stacks. So, if the projection_x_coord and projection_y_coord units=m [ie "meters in a plane tangent to the idealized earth nadir point"], the netcdf-java library could then be asked to apply a transform to the coordinate data to view vectors [radians] prior to reprojection calculations. I can see that this can be done in the GEOSTransform.java; I'll have to read it and the HRIT manual again to get a better idea of what's common and where the transform to/from metres should go. Cheers, Leon From: Tom Rink [mailto:rink@xxxxxxxxxxxxx] Sent: Thursday, 9 July 2015 3:32 AM To: netcdf-java@xxxxxxxxxxxxxxxx Subject: Re: [netcdf-java] Geostationary CF grid_mapping problem: "HTTP Status 500 - Internal Server Error" [SEC=UNCLASSIFIED] Hi Leon, I worked with Martin, John Caron and others to define this standard, and developed the software on the Java side, so maybe I can help: This transformation is formed by the cross product of two arithmetic progressions, one in W-E direction, the other S-N, forming a set of view vectors from an idealized point in the Earth's equatorial plane measured in radians. It should be possible to compute these vectors from a set of (x,y) measured in meters in a plane tangent to the idealized earth nadir point thus using most of the same software to support both transformation definitions. Tom On 7/8/15 3:03 AM, Leon Majewski wrote: Hi Ryan, all, cc Martin, I've found the issues, but they raise some questions. How to get my gdal example to display WMS GetCapabilities: According to cdm/src/main/java/ucar/nc2/constants/CF.java, the grid_mapping_name attribute needs to be "geostationary", rather than "geostationary_satellite" (as created by gdal) ncatted -a grid_mapping_name,geostationary_satellite,m,c,geostationary geos.nc According to cdm/src/main/java/ucar/unidata/geoloc/projection/sat/Geostationary.java "fixed_angle_axis" or "sweep_angle_axis" is mandatory (not created by gdal) ncatted -a sweep_angle_axis,geostationary_satellite,c,c,y geos.nc Need to rename so attributes to match code ncrename -a geostationary_satellite@satellite_height,perspective_point_height geos.nc ncrename -a geostationary_satellite@longitude_of_central_meridian,longitude_of_projection_origin geos.nc netcdf-java code doesn't seem to handle inverse flattening, change to semi_minor_axis: ncrename -a geostationary_satellite@inverse_flattening,semi_minor_axis geos.nc ncatted -a semi_minor_axis,geostationary_satellite,m,f,6356752.3 geos.nc Once these attributes are fixed, the layers are shown by the WMS GetCapabilities request. Great... However, the GetMap doesn't work as expected ?FORMAT=image/jpeg&SERVICE=WMS&VERSION=1.3.0&REQUEST=GetMap&STYLES=boxfill/greyscale&WIDTH=800&HEIGHT=400&CRS=CRS:84&BBOX=0,-90,360,90&LAYERS=Band2&COLORSCALERANGE=0,255 Should effectively be the same as the result of: gdalwarp -t_srs '+proj=latlong' -te 0 -90 360 90 -ts 800 400 NETCDF:geos.nc:Band1 out.tif -co "COMPRESS=JPEG" -ot Byte (insert image... might not work) [cid:image001.jpg@01D0BA1B.D0022830] But the response only shows one pixel/colour. This is because gdal, proj4 and pyproj... use units of 'm' for their transforms, whereas this implementation seems to want to use radians (scan angle) . ncdump -v x geos.nc x = -5498000 ... 5498000 Adding a guess at a scale factor for x, y ncatted -a scale_factor,x,c,f,0.00000003 geos.nc ncatted -a scale_factor,y,c,f,0.00000003 geos.nc This time, the request shows some data, but obviously incorrect. (insert image... might not work) [cid:image002.jpg@01D0BA1B.D0022830] So... there seems to be a difference in the units expected by GDAL/PROJ4 and netcdf-java (and potentially CF). Is there a way to support "unit=m" within netcdf-java and the CF standard? Alternatively proj4/gdal would need to be updated to handle "units=rad" I'm eager to hear your thoughts. Cheers, Leon From: Leon Majewski Sent: Tuesday, 19 May 2015 5:36 AM To: 'Ryan May' Cc: netcdf-java@xxxxxxxxxxxxxxxx<mailto:netcdf-java@xxxxxxxxxxxxxxxx> Subject: RE: [netcdf-java] Geostationary CF grid_mapping problem: "HTTP Status 500 - Internal Server Error" [SEC=UNCLASSIFIED] Hi Ryan, I'll ask our admin to upgrade or spin up a vm. In the meantime, here's a simple script to generate a file with similar issues (WMS page appears, but no layers). # get some blue marble data (small): wget http://earthobservatory.nasa.gov/Features/BlueMarble/Images/land_shallow_topo_2048.tif # add a projection gdal_translate -a_srs '+proj=longlat' -a_ullr -180 90 180 -90 land_shallow_topo_2048.tif map.tif # remap the data to our location (actually, use 80.5 due to dateline artefacts) # output CF netcdf gdalwarp -r cubic -tr 4000 4000 -t_srs "+proj=geos +lon_0=80.5 +h=35785863 +a=6378137.0 +b=6356752.3" -te -5500000 -5500000 5500000 5500000 map.tif geos.nc -of NETCDF -co "COMPRESS=DEFLATE" Cheers, Leon From: Ryan May [mailto:rmay@xxxxxxxx]<mailto:[mailto:rmay@xxxxxxxx]> Sent: Tuesday, 19 May 2015 1:56 AM To: Leon Majewski Cc: netcdf-java@xxxxxxxxxxxxxxxx<mailto:netcdf-java@xxxxxxxxxxxxxxxx> Subject: Re: [netcdf-java] Geostationary CF grid_mapping problem: "HTTP Status 500 - Internal Server Error" [SEC=UNCLASSIFIED] Leon, Version 4.6.1 of THREDDS was just released. Could you see if that fixes your problem? ftp://ftp.unidata.ucar.edu/pub/thredds/4.6/current/thredds.war If not, it would be really helpful to get a sample of the problematic file so we can try to reproduce locally. Thanks, Ryan On Wed, May 13, 2015 at 12:06 AM, Leon Majewski <Leon.Majewski@xxxxxxxxxx<mailto:Leon.Majewski@xxxxxxxxxx>> wrote: Hi all, > It's been suggested that I use the CF1.7 grid_mapping geostationary I found that I need to set the grid_mapping_name to "geostationary_satellite" float geostationary ; geostationary:grid_mapping_name = "geostationary_satellite" ; > HTTP Status 500 This fixes the HTTP Status 500. However, this results in their being no queryable layers in the WMS and netcdf subset service fails [both worked with vertical_perspective]. The WMS GetCapabilities for the vertical perspective version includes: <Layer><Title>AGLS observations product suite</Title> <Layer queryable="1"><Name>channel_0013_brightness_temperature</Name> <Title>brightness temperature for channel 13 at 10.41 um</Title> <Abstract>brightness temperature for channel 13 at 10.41 um</Abstract> <EX_GeographicBoundingBox><westBoundLongitude>-180.0</westBoundLongitude><eastBoundLongitude>180.0</eastBoundLongitude><southBoundLatitude>-90.0</southBoundLatitude><northBoundLatitude>90.0</northBoundLatitude></EX_GeographicBoundingBox> <BoundingBox CRS="CRS:84" minx="-180.0" maxx="180.0" miny="-90.0" maxy="90.0"/> <Dimension name="time" units="ISO8601" multipleValues="true" current="true" default="2015-02-20T00:00:20.000Z">2015-02-20T00:00:20.000Z</Dimension> ... </Layer> While the geostationary_satellite version has: <Layer><Title>AGLS observations product suite</Title> </Layer> Has anyone see this behaviour/been able to work around it? Thanks, Leon _______________________________________________ netcdf-java mailing list netcdf-java@xxxxxxxxxxxxxxxx<mailto:netcdf-java@xxxxxxxxxxxxxxxx> For list information or to unsubscribe, visit: http://www.unidata.ucar.edu/mailing_lists/ -- Ryan May Software Engineer UCAR/Unidata Boulder, CO _______________________________________________ netcdf-java mailing list netcdf-java@xxxxxxxxxxxxxxxx<mailto:netcdf-java@xxxxxxxxxxxxxxxx> For list information or to unsubscribe, visit: http://www.unidata.ucar.edu/mailing_lists/
